4.15.1

Adding a staff when missed by recognition

Occasionally, a staff inside a system may not be localized during recognition due to

flaws in the original score (or if the scanned page is severely skewed. If there is a

missing staff line in the ENF display, it can be reconstructed quite easily as follows:

a.  First, you want to re-link parts in the shorted system. Position the cursor

inside the system and hit Ctrl + L to open Re-link Parts.

b.  Put a check next to the appropriate visible parts. Leave the missing part

unchecked. Make sure the parts you check correspond to the visible staffline

and the missing part is unchecked. Hit OK.

c.  Select the Properties tool. Yellow arrows along the left system bracket will

indicate all known parts, visible or invisible.

d.  In the affected system, click on the yellow arrow of any staff and put a check

mark next to "Visibility". Make sure "Show Staff" is also selected.

e.  In the "Apply To:" pull-down menu, select "Current Staffline or System".

f.  Hit the "U" key and select Unify Key Signatures (based on First System).

Hit OK and the key signatures of the score will become unified. Now you

need only to fill in the missing notes. Remember you can always use Copy

and Paste to clone measures of notes at a time whenever possible.

4.16

Working with audio sound libraries (Plug-ins)

SmartScore hosts third-party sound libraries compiled for VST (for Windows) and

Audio Units (for Macintosh). Some sound libraries may not be supported. Libraries

and players that have been tested and are known to work with SmartScore X are Kon-

takt® and Kontakt2® players (e.g. Garritan® libraries) and MOTU® MachFive®

library and player.
